 台积电采购日本安立计表面温度计日本安立计表面温度仪主机HD-1300E//表面温度仪探头A-234E-02-1-TC1-ASP 表面温度仪探头A-234E-02-1-TC1-ASP
 ANRITSU-METER, 温度测量,一言之仅此语词中就凝聚了日本安立计器公司ANRITSU-METER的全部历史和技术. 1963年发明了通过热电偶测量表面温度的技术以来,"ANRITSU安立式"测温棒始终居于世界该行业的领先地位. 对温度绝对值的执着和契而不舍的开发精神,以及一条龙生产体制和严格的质量管理使得生产的种种测温棒仪器赢得众多客户的信赖。
| Model |
HD-1750 |
| Display |
LCD with Backlight |
| Waterproof specifications |
Equivalent to IPX5 |
| Input connector |
ANP |
| Input type |
Thermocouple Input: Type E, K*1 |
| Channel |
1ch |
| Signal source resistance |
MAX.500ohm |
| Measurement Range |
1°C Resolution |
E |
-200 to 800°C |
| K |
-200 to 1370°C |
| 0.1°C Resolution |
E |
-104.9 to 504.9°C
(Switches automatically to 1°C resolution range when messured temperatures fall outside the 0.1°C resolution range.)
|
| K |
-104.9 to 504.9°C
(Switches automatically to 1°C resolution range when messured temperatures fall outside the 0.1°C resolution range.)
|
| Measurement Accuracy |
1°C Resolution |
0°C to |
± (0.1% of reading +1°C) |
| to 0°C |
± (0.5% of reading +1°C) |
| 0.1°C Resolution |
0°C to |
± (0.05% of reading + 0.2°C) |
| to 0°C |
±0.5°C |
| Reference junction compensation accuracy |
±0.2°C at 25°C±10°C |
| Temperature Coefficient |
±0.01% of F/S per °C (F/S : full scale) |
| Operation Environment |
0 to 40°C, 0 to 80%RH (Non condensing)
32 to 104°F, 0 to 80%RH (Non condensing)
|
| Storage Environment |
-20 to 50°C, 0 to 85%RH (Non condensing)
-4 to 122°F, 0 to 85%RH (Non condensing)
|
| Battery life |
300h |
| Power supply(Dry battery) |
4 AA Alkali Batteries |
| Power supply(AC power) |
- |
| Sampling rate |
approx.300ms |
| Linearlizer |
Digital Linearizer method (Compliant with IEC 60584-1 (2013)) |
| Dimensions(mm) |
approx. 76(w)×167(H)×36(D) [Protruded parts excluded] |
| Weight |
approx. 350g [Include Batteries] |
| Supplied accessories |
Manual,Test report,Soft case, |
| Hand strap,4 AA Alkaline batteries |
| Optional accessories |
- |
| Alarm Output |
- |
| Analog Output |
- |
| Compatible standards |
CE Marking, RoHS |
*1 Details of typeJ,T,R(option)
|
